Off-Grid survival kit 4kWh 3kVA

OG4kWh3kVA
Valutazione

Full OffGrid kit !

Zombie Apocalypse, Pandemic, don t worry with this kit you won t run out of electricity !

With a continuous output power of 3 000 W and a storage capacity of 4 kWh, this kit will produce and provide enough energy for a small house, mobile home, boat, etc...

Solar Pannels
Assembled and wired
3.190,00 €
Quantità



Security policy



Delivery policy (TNT)



Return policy (14 days)

Descrizione

This kit includes :

(optionnal)Solar Pannels GES-M 310 PERC monocritalin
(sold with 12m cable 6mm2 and connectors)
Module Type : STM6-310/60
Maximum Power (Pmax) : 310Wp
Maximum Power Voltage (Vmp) : 33.00V
Maximum Power Current (Imp) : 9.40A
Open-circuit Voltage (Voc) : 40.50V
Short-circuit Current (Isc) : 9.92A
Module Efficiency STC (%) : 18.94%
Power Tolerance : 0~+5W
Weight : 18.0 kg (39.68 lbs.)


1 x Victron EasySolar II
INVERTER/CHARGER
PowerControl & PowerAssist Yes
Transfer switch 32A
Maximum AC input current 32A
Auxiliary output Yes (32A)

INVERTER
Input voltage range 38 – 66V
Output voltage: 230 VAC ± 2%
Frequency: 50 Hz ± 0,1% (1)
Cont. output power at 25°C (3) 3000VA / 2400W
Cont. output power at 40°C / 65°C 2200W / 1700W
Maximum apparent feed-in power 2500VA
Peak power 5500W
Maximum efficiency 95%

CHARGER
Input voltage range: 187-265 VAC
Input frequency: 45 – 65 Hz
Maximum battery charge current (4) 35A
Battery temperature sensor Yes
Programmable relay (5) Yes
VE.Bus communication port
For parallel and three phase operation,
remote monitoring and system integration
General purpose com. port Yes, 2x

SOLAR CHARGE CONTROLLER
Model SmartSolar MPPT 250/70-Tr
Maximum output current 70A
Maximum PV power 4000W
Maximum PV open circuit voltage 250V
Maximum efficiency 98%
Self-consumption 20mA

GENERAL
Interfaces VE.Can, USB, Ethernet, VE.Direct, wifi
Remote on-off Yes
Operating temp. range -40 to +65°C (fan assisted cooling)
Humidity (non-condensing): max 95%

ENCLOSURE
Material & Colour aluminium (blue RAL 5012)
Protection category IP21
Battery-connection M8 bolts
PV connection M6 bolts
230 V AC-connection Screw terminals 13 mm2 (6 AWG)
Weight 26kg
Dimensions (hxwxd) 506 x 275 x 237 mm


1 x Lithium Battery pack 4 kWh
(48V nominal made from 1 BMWi3 module, Fuse holder + Fuse, power relays TE, precharge, current sensor, maintenance switch and BMS with CAN communication with EasySolar II)
Watercooling (optionnal)
Tesla modules sold with capacity certification
Pack size : 900 x 640 x 100mm
Pack weight : 60kg



THIS IS A PLUG AND PLAY SYSTEM !


Dettagli del prodotto
OG4kWh3kVA
10 Articoli
Recensioni

Ancora nessuna recensione da parte degli utenti.

Scrivi la tua recensione

Off-Grid survival kit 4kWh 3kVA

Off-Grid survival kit 4kWh 3kVA

Full OffGrid kit !

Zombie Apocalypse, Pandemic, don t worry with this kit you won t run out of electricity !

With a continuous output power of 3 000 W and a storage capacity of 4 kWh, this kit will produce and provide enough energy for a small house, mobile home, boat, etc...
